Plasma Cutting Machine

  • GC1530P GC1540P GC2040P Plasma Cutter Cutting Machine With US Hypertherm China LGK Huayuan Power Supply
  • GC1530P GC1540P GC2040P Plasma Cutter Cutting Machine With US Hypertherm China LGK Huayuan Power Supply
  • GC1530P GC1540P GC2040P Plasma Cutter Cutting Machine With US Hypertherm China LGK Huayuan Power Supply
  • GC1530P GC1540P GC2040P Plasma Cutter Cutting Machine With US Hypertherm China LGK Huayuan Power Supply
  • GC1530P GC1540P GC2040P Plasma Cutter Cutting Machine With US Hypertherm China LGK Huayuan Power Supply
  • GC1530P GC1540P GC2040P Plasma Cutter Cutting Machine With US Hypertherm China LGK Huayuan Power Supply
GC1530P GC1540P GC2040P Plasma Cutter Cutting Machine With US Hypertherm China LGK Huayuan Power SupplyGC1530P GC1540P GC2040P Plasma Cutter Cutting Machine With US Hypertherm China LGK Huayuan Power SupplyGC1530P GC1540P GC2040P Plasma Cutter Cutting Machine With US Hypertherm China LGK Huayuan Power SupplyGC1530P GC1540P GC2040P Plasma Cutter Cutting Machine With US Hypertherm China LGK Huayuan Power SupplyGC1530P GC1540P GC2040P Plasma Cutter Cutting Machine With US Hypertherm China LGK Huayuan Power SupplyGC1530P GC1540P GC2040P Plasma Cutter Cutting Machine With US Hypertherm China LGK Huayuan Power Supply

GC1530P GC1540P GC2040P Plasma Cutter Cutting Machine With US Hypertherm China LGK Huayuan Power Supply

  • Hypertherm Generator
  • Water Tank
  • Large Working size for option
  • StarFire Controller With THC
  • Product description: Plasma Cutting Machine Can Cut Metal Sheet, Very High speed to Cut Carbon Steel, Stainless Steel, Galvanized Plate
  • INQUIRY   EMAIL


What is CNC plasma cutter?
CNC plasma cutting machine is a machine for processing metal materials by means of plasma cutting technology. With different gases, it can also cut a variety of metals which is difficult to cut by oxygen cutting , especially for non-ferrous metals (stainless steel, carbon steel, aluminum, copper, titanium, nickel). With the advantages of fast cutting speed, smooth cut surface, little heat distortion and almost no heat affected zone, plasma cutting machines are widely used in automobiles, locomotives, pressure vessels, chemical machinery, nuclear industry, general machinery, engineering machinery, steel structures and other industries!



Model

GC1530P GC1540P GC2040P

Working  area (X-Y)

1500mmx3000mm  1500*4000mm  2000*4000mm

Working  material

Iron, Steel, Aluminum sheets, Galvanized sheets, Titanium Plates

Working  Thickness

0.5-40mm

Cutting Speed

0-8000mm/min

Power

15kw

Input Voltage

380V 50HZ (or according to your need)

Plasma Current

63A/100A/120A/160A/200A/300A

Connecting Way

USB

Working Mode

Untouched arc striking

Cooling method

With water pump and tank provide circulating water cooling

Z axis travel

0-70mm

The automatic elastic raise

0-5mm

Rail guide

Precision work round

Transmit way

Taiwan imported ball screw

Operation language

English (Option)

Command

G code, *uoo, *mmg, *plt

Optional power source

USA brand Hypertherm powermax 45 65 85 105 125 200

Spare parts

Electrode ,Electricity nozzle and Water jacket


Features of CNC plasma cutter for Sheet Metal

1. Welded structure of thickening square tube, together with top brand guide rail to ensure high running speed and accuracy.


2. Hypertherm plasma power supply together with high sensitive arc pressure adjuster. Self-adjusting can choose the best distance between plasma gun and working piece automatically to ensure high accuracy cutting.


3. CNC pasma cutter for sheet metal uses STARFIRE control system with FastCAM software for auto material saving function, large capacity storing function, convenient to read and process.


4. Cutting head with cooling system can quickly cool surface of material to avoid burr and residue.


5. Overall stepper motor with high precision rack and pinion, to ensure the cnc plasma cutter has small noise, smooth, precise coordinates of the mobile performance.


6. Perfect software compatibility, such as Ucancam, Type 3, Artcum, etc.
