Plasma Cutting Machine

  • Large Size 1500*3000mm 2000*6000mm Plasma Cutting Machine For Metal
  • Large Size 1500*3000mm 2000*6000mm Plasma Cutting Machine For Metal
  • Large Size 1500*3000mm 2000*6000mm Plasma Cutting Machine For Metal
  • Large Size 1500*3000mm 2000*6000mm Plasma Cutting Machine For Metal
  • Large Size 1500*3000mm 2000*6000mm Plasma Cutting Machine For Metal
Large Size 1500*3000mm 2000*6000mm Plasma Cutting Machine For MetalLarge Size 1500*3000mm 2000*6000mm Plasma Cutting Machine For MetalLarge Size 1500*3000mm 2000*6000mm Plasma Cutting Machine For MetalLarge Size 1500*3000mm 2000*6000mm Plasma Cutting Machine For MetalLarge Size 1500*3000mm 2000*6000mm Plasma Cutting Machine For Metal

Large Size 1500*3000mm 2000*6000mm Plasma Cutting Machine For Metal

  • 1500*3000mm 2000*3000mm 2000*4000mm 2000*6000mm
  • Metal Sheet Cutting Plasma Cutter
  • Air compressor option
  • Starfire control system+THC
  • Product description: Plasma cutting machine application: Processing shells of machinery and electronic products, advertising signs, crafts, iron garden, car manufacture, boat building, electrical accessories, board cuttin
  • INQUIRY   EMAIL

Large Size 1500*3000mm 2000*6000mm Plasma Cutting Machine For Metal


Technical Parameter

Model

GC1530P Plasma cutting machine (high configuration)

X,Y working area

1500*3000mm

Z working area

150mm

Body dimension

2000mm*3100mm*1450mm

Packing dimension

2200mm*3400mm*1550mm

Lathe bed

Very thick steel structure

Machine Power

8.5kw

Working voltage

380V three phase/ 60hz

Reposition precision

0.02mm

Processing precision

0.1mm

Maximum cutting speed

12000mm/min

Torch Height control mode

Automatic

Cutting thickness

Max 12mm carbon steel

Plasma power supply

China LGK 63A

Control system

STARfire

Motors

Stepper motor

Software

Starcam

Weight

2450KGS

Plasma Air Pressure

Max.0.8Mpa

Working Temperature

-10°C-60°C. Relative Humidity, 0-95%.

LCD Display Dimension

7 Inches


1 .The machine is all welded as seamless steel structure. Steady structure and long life time

2. High configuration, high cutting speed and precision.

3. Auto ARC starting. Steady performance.

4.Control system: DSP handset control, with USB interface

5. Cutting material: steel, copper, iron, aluminum, galvanized sheet, titanium plates, and so on.

6. File format: G-code

7.Suitable Software : Artcut, Type3, ArtCAM. Beihang Haier.

Option:

1.Different working size:
1300X2500MM /1500X3000MM /1500X6000MM /2000X4000/2000X6000MM or other sizes according to customers needs

2.Servo motors and drivers

3.Different power: 65A / 100A / 130A /200A for different thickness cutting

4.Torch Height control system

Applicable materials

Iron plate, aluminum plate, titanium, stainless steel plate, galvanized sheet, white steel plate, metal materials.
