GC1325W 1325 CNC Router with Water Tank for Wood Aluminum

  • With water tank
  • 1300*2500
  • For engraving aluminum
  • Spray water cooling system
  • Product description: With water tank and spray water cooling system for aluminum soft metal. DSP controller 1300*2500mm working size
  • INQUIRY   EMAIL

GC1325W 1325 CNC Router with Water Tank for Wood Aluminum

Parameters
Model
GC-1325
Driver and Inverter
leadshine driver and fuling inverter
X Y Z Traveling Area
1300mm*2500mm*200mm
Table Structure
Aluminum T-Slot
Spindle Power
3.2KW Water Cooling
Cooling system
Spray water cooling system
Water tank Yes
Ball screw
Taiwan TBI
Max. Spindle Speed
24000r/min
Max. Traveling Speed
12000mm/min
Max. Working Speed
8000mm/min
Processing Accuracy
±0.025mm
Reposition Accuracy
≤0.025mm
Driving System
Stepper Motor or Servo Motor
Operation System
NC-STUDIO (optional DSP/Mach 3)
Software
Type3, Artcam, Ucancam
Working Voltage
AC 220/380V
Net Weight/Gross Weight
1250 KG/ 1400KG



Feature:

1. High accuracy ball bearing guide screw of taiwan,minimize the slit.

2. Imported linear rail,self lubricating glide.

3. Our routers have the features of recarving after stop and the power failure may be restored.

4. Unique preservation way of the zero point.

5. Use for long time and no distortion.

6. This type is also suitable for advertisement.

7. Iron cast wholly frame, double- screw auto eliminating ball screw, floor-type linear guide transmission.

8. High power water cooling brushless motor

9. Stepper motor could enhance work efficiency.

10. Break-point memory pointesfor 10 pcs, reducing material waste.

11.High compatibility, applicable for CNC software: type3, Artcam, Castmate, Pore, Weitai, variable CAD/CAM etc. It is easily to process relief sculpture, shadow carving, three dimension characters in fancy style etc.


Application:

1. Wood Furniture Industry: Wave Plate, fine pattern, antique furniture, wooden door, screen, craft sash, composite gates, cupboard doors, interior doors, sofa legs, headboards, soft metal and so on.

2. Advertising Industry: Advertising identification, sigh making, Acrylic engraving and cutting, crystal word making, blaster molding, and other advertising materials derivatives making.

3. Die Industry: A sculpture of copper, aluminum, iron and other metal molds, as well as artificial marble, sand, plastic sheeting, PVC pipe, wooden planks and other non-metallic mold.
