UV Laser Marking Machine

  • Marking area: 110*110mm
  • Laser source: UV Laser
  • Laser head: Galvenometer Head
  • Marking Depth: 0 ~0.5mm
  • Product description: uv laser marking machine, metals and some non-metals marker, Raycus/ IPG 5w/ 10w/ 15w laser marking
  • INQUIRY   EMAIL

VU Laser Marking Machine



GoodCut uv laser marking is used to work with laser to mark / printer on different materials for remark, logo, serial No., bar code, 2D code, date, Numbers etc.

And because it can work on almost any kind of material, now more and more popular and be widely used.


Adopts advanced digital high speed scanning galvanometer, quick speed without deviation, small volume, good stability, and performance reached the international advanced level.

Main features of uv laser marking:

It conforms to European CE standards and is equipped with high-speed scanning galvanometer. It has high precision and high speed and can replace manual sand blasting. The software control system is used for Windows interface. It supports multiple file formats including Al, JPG, CDR, BMP and so on. Automatic marking, easy to operate. DEM and wholesale.

Low Power DPSS UV Lasers(3W/5W) is featured with compact structure with extremely convenient installation and debugging. They have adopted the built-in laser diode technology to avoid the effect of fiber shaking on output laser. Besides, the beam quality is excellent enough to ensure the stability and reliability for mass production, which can meet the special manufacturing and processing demand in harsh industrial working condition..

Parameter of laser marking machine for metal:

3W 5W 10W UV fiber laser marking machine

Common power

3W/5W/10W/15W

Laser wavelength

355nm

Frequency Range

20-100HZ

Pulse Width

<15ns

Output beam quality(M2)

<1.5

Minimum focus spot

0.01mm

Minimum line width

0.01mm

Minimum character

0.06mm

Repeatability

0.001mm

Marking speed

<7000mm/s

Marking depth

0.01-0.5mm(According to the material)

Marking area

110x110mm

Optional marking area

70x70mm/140x140mm/175x175mm/200x200mm/300x300mm

Cooling way

Wateri cooling

Voltage

110V/220V±10%

Total power consumption

700-1000W

UV laser marking machine is developed by using a 355nm UV laser, it adopts third-order cavity frequency multiplication technology. Compared to infrared laser, the focusing spot of UV laser is much smaller, which helps to reduce the mechanical deformation of the materials to a large extent. It features of smaller heat affected area and more beautiful marking effect.

355nm high quality uv laser marking for clocks and watches and glasses











Free Shipped  UV 3w 5w / 30w fiber laser marking machine price Laser for metal

Product Type:Laser Marking Machine
Marking Materials:Both metals and some non-metals
Metals: carbon steel/mild steel, stainless steel, aluminum, copper, magnesium, zinc; rare metal and alloy steel (gold, silver, titanium, etc.); special surface treatment (aluminum anodized, plating surface, surface oxygen breaking of aluminum and magnesium alloy)
Non-metals: plastics, rubber, resin, carton box, glass, etc.

UV laser marking / engraving nail polish bottle and prefume bottle,perfume bottles, wine glasses
