  • 4 Axis CNC Router with 9KW Rotated ATC Spindle for Engraving 3D Wood Working
  • 4 Axis CNC Router with 9KW Rotated ATC Spindle for Engraving 3D Wood Working
  • 4 Axis CNC Router with 9KW Rotated ATC Spindle for Engraving 3D Wood Working
  • 4 Axis CNC Router with 9KW Rotated ATC Spindle for Engraving 3D Wood Working
4 Axis CNC Router with 9KW Rotated ATC Spindle for Engraving 3D Wood Working4 Axis CNC Router with 9KW Rotated ATC Spindle for Engraving 3D Wood Working4 Axis CNC Router with 9KW Rotated ATC Spindle for Engraving 3D Wood Working4 Axis CNC Router with 9KW Rotated ATC Spindle for Engraving 3D Wood Working

4 Axis CNC Router with 9KW Rotated ATC Spindle for Engraving 3D Wood Working

  • Linear atc device
  • 180 degree spindle
  • High Z axis
  • Sunk table
  • Product description: Big size for optional 10/12 pcs linear auto tool change magazine HQD 9kw rotated spindle for engraving 3d work Servo motor and driver Taiwan HIWIN guide rails
  • INQUIRY   EMAIL

4 Axis CNC Router with 9KW Rotated ATC Spindle for Engraving 3D Wood Working


Advantages:
1. Big steel tube welded structure, after aging and tempering treatment, reliable and stable and not easy to deformation.
2. Top-quality components, HSD/HQD 4 axis ATC spindle, Delta inverter, TBI ball screw, Yaskawa servo motors, Syntec control system and so on. Long-time working time, high precision and efficiency.
3. Linear Tool Magazine system with 8/10/12 forks and tool holders , which is loaded with the spindle, make the 4 axis wood CNC machine change tools quickly and save time.
4. Many optional configuration and OEM service available. According to your requirement, different configurations will be offered.


Parameter:
Working area: 1300x2500x500mm /2000*3000*600mm
Spindle type: air cooling ,ATC spindle
Spindle power 9.0 kw
Spindle rotating speed 0-18000rpm
Power supply: 380,50/60hz ,3 phases
Worktable: vacuum and t-slot working table
Locating precision: <0.01mm
Min shaping character: Character:3x3mm,letter:2x2mm
Operating temperature: 5°C-40°C
Working humidity 30%-75%(without condensed water)
Working precision ±0.03mm
System resolution ±0.001mm
Control configuration: syntec system with USB ethernet
Data transfer interface: USB/PC
System environment: windows 7 ,8 .10
Spindle cooling way: air cooling by itself by fan
Graphic format supported: G code: *.u00, * mmg, * plt, *.nc
Compatible software ARTCAM, UG,powermill etc.
Cutting thickness: 0-40mm also (depends on different material)
Z tool censor:  yes
Whole machine dimension: 3680x2270x1900mm


Main Feature:


1. HSD spindle: original famous brand from Italian, you also can choose Hitech spindle and Chinese HQD spindle.
2. SYNTEC control system: from Taiwan with high performance and competitive price.
3. Yaskawa servo motor and drives: from Japan with high precision and long life.
4. HIWIN linear guide: from Taiwan, it is used for linear reciprocating stadium.
5. Working area: 1300*2500*400mm, other size for optional, C Rotary Axis: 180 degree.
6. Whole welded steel structure thicken to 10mm.
7. Drive System: X, Y-Rack Z-Ball Screw, Z with high precision ball screw.
8. Automatic lubrication: To lubricate rail and slide block , make it run better.
9. Schneider electrical components: original brand from France.
10. Japanese Omron Switch with long life.
11. Shimpo Reudcer from Japan: More powerful and higher precision.
12. Vacuum & T-Slot table with Aluminum sheel: Use vacuum pump and clamp fixed materials.
13. Automatic tools change cnc machine with 12pc tools


Detailed Parts:

1. Rotate head

Make spindle rotate at C axis to 180°, suitable for side drilling and cutting


2. Syntec controller system:

(1).With separate control board,easy and convient to operate.

(2).More than 20 years experience on cnc,with mature technology


3. Leadshine servo motor and driver/ Japan YASKAWA Servo driver and motor



-With strong power and high precision





1)We use top-quality four-row imported ball bearing, wide linear lead rail and self-lubricating block for the machine. It can balance the force in all directions to ensure the machine’s accuracy and strength when engraving.

2)The route of Z axis can be heightened to 600mm, so it is suitable for processing large-scale and super-thick material.

3)The design documents of intelligent processing cross-border protection can prevent the excessive process caused by mechanical impact.

4)The diversified processing speed can be controlled separately. The speed of idle running and roll setting improve the quality of processed products and processing efficiency greatly.


Application:
1) Mould: wood,wax, wood, gypsum,foams,wax.
2) Furniture: wooden doors, cabinets, plate, office and wood furniture, tables, chair, doors and windows.
3) The wood products: voice box, game cabinets, computer tables, sewing machines table,instruments.
4) Plate processing: insulation part, plastic chemical components, PCB, inner body of car, bowling
tracks, stairs, anti bate board, epoxy resin, ABS, PP, PE and other carbon mixed compounds.
5) Decorate industry: Acrylic, PVC, MDF, artificial stone, organic glass, plastic and soft metals such as copper, aluminum plate engraving and milling process

Inquiry:

CONTACT US

Contact: Smile Ji

Phone: 008618396857273

Tel: 008618396857273

Email: smileji@goodcutcnc.com

Add: Zhiye Science and Technology Park, No. 1117 Kaituo Road, High-tech District, Jinan City, Shandong, China
