Usage Tips

The Daily Need Of Metal Laser Cutting Machine Maintenance And Maintenance Note

Cleaning of guide rails: It is recommended to clean once every half month. When cleaning, it needs to be turned off after operation.

As one of the core parts of the equipment, guide rail and straight shaft function is to guide and support. In order to ensure that the machine has higher machining accuracy, it is required that the guide rails and straight lines have higher guiding precision and good movement stability. During the operation of the equipment, due to the large amount of corrosive dust and smoke generated by the processed parts during processing, these fumes and dust are deposited on the surface of guide rails and straight axes for a long time, which has a great impact on the machining accuracy of the equipment. In addition, etching points will be formed on the surface of the linear axis of the guide rail to shorten the service life of the equipment. In order to ensure the normal and stable operation of the machine and ensure the quality of the product, we must carefully do the daily maintenance of guide rails and straight axes.

How specific cleaning, by our after-sale personnel explained on the spot.

Inspection of the light road

The light path system of the laser cutter is completed by the reflection of the reflector and the focus of the focusing mirror. There is no deviation problem for the focusing mirror in the light path, but the three mirrors are fixed by the mechanical part. The possibility of offset is greater. Although there is usually no offset, it is recommended that users check that the light path is normal before each work.

Clean the lenses: It is recommended to clean the equipment before work every day. The equipment must be turned off.

Note: 1. The lens should be gently rubbed, and the surface should not be damaged; 2. The wiping process should be lightly handled to prevent falls; 3. Be sure to keep concave face down when focusing mirror is installed.

How specific cleaning, by our after-sale personnel explained on the spot.

IV. Fan Cleaning

The use of fans for a long time will make the fan surface accumulate a lot of solid dust, so that the fan produces a lot of noise, but also not conducive to exhaust and deodorizing. When there is a lack of fan suction, first turn off the power supply, remove the air intake and exhaust pipe from the air turbine, remove the dust inside, and then stand on your head and pull out the wind leaves until it is clean. Then install the fan.

Tightening of screws and coupling joints

After the motion system is working for a period of time, the screws and coupling joints at the motion connection will loosen, which will affect the stability of the mechanical movement. Therefore, it is necessary to observe whether the transmission parts have different sounds or abnormal phenomena during the operation of the machine. Be firm and maintain when problems are detected. At the same time, the machine should use tools to strengthen the screws one by one for a period of time. The first firmness should be about one month after the equipment is used.

Cleaning of water tanks

Recommendation: Wash the water tank once a week and replace the circulating water.

Note: The laser tube must be filled with circulating water before the machine works.

The water quality and water temperature of the circulating water directly affect the service life of the laser tube. It is recommended to use pure water and control the water temperature below 35 °C. Replacement of circulating water if above 35 °C. (Users are advised to choose a cooler or use two water tanks).

If the temperature in the northern region is very low in winter, it may cause the water in the laser tube to ice. It can be properly added with antifreeze to prevent the water from freezing and cause the laser tube to break.
