GC6090 Factory Supply High Quality Desktop Mini Cnc Metal Router Milling 6090 For Stone

  • 600 x 900mm working area
  • Thicken heavy duty body
  • Servo motor
  • X, Y, Z axis ball screw transmission
  • Product description: Working area: 600 x 900mm Structure: Thicken heavy duty body, stable working Motor: Servo motor Transmission: X, Y, Z axis ball screw transmission
  • INQUIRY   EMAIL

Factory Supply High Quality Desktop Mini Cnc Metal Router Milling 6090 For Stone


Main features

1. Desktop Mini Cnc 6090 Router can be used for metal and stone

2. Working area: 600 x 900mm
3. Structure: Thicken heavy duty body, stable working
4. Motor: Servo motor
5. Transmission: X, Y, Z axis ball screw transmission

X, Y, Z axis with dustproof

6. With water tank,special for metal stone materials engraving



Parameters of Factory Supply High Quality Desktop Mini Cnc Metal Router Milling 6090 For Stone


Model
GC6090
X,Y,Z working area
600×900×150mm
Table size
600×900mm
Strong structure
Thicken heavy duty body
X,Y,Z Transmission
X,Y ,Z German ball screw
Spindle
1.5kw Water Cooled Spindle
Spindle power rate
1.5kw
Spindle rotating speed
0-24000rpm/min
Drive motor
Servo motor
Max. Speed
12m/min
Working speed
6m/min
Precision
0.05mm/300mm
Repositioning Accuracy
0.02mm
collet /Tool diameter
3.175 --12.7mm
Holding down mode
clamp
voltage
AC220V/50Hz
Operating system
DSP offline system (Ncstudio system optional)
Interface
USB port
Command
HPGL,G code, u00, mmg, plt
Compatible Software
Type3, Artcam, Ucancam, Casmate / Proe / UG / Artgrave etc.



Parts images


Oil lubrication system




Dust-proof and waterproof design protects the transmission components.

All surroundings of stone cnc router is with stainless steel cover to avoid machine be dusted after long time operation, also All axis use dust proof cover to protect guide rail from water




4.5kw /5.5kw Water cooling spindle

with water tank, special for metal stone materials engraving




Thicken heavy duty body , solidity and stable




Our services

After-sales Service:

1. Machine warranty: the warranty is 12 months after shipment date. During the warranty period, the main accessories (except the wearing parts) are replaced free of charge because of the quality problems under the normal operation. but due to improper operation,  also well-solved, but not free of charge.

2. We have an experienced after-sales team and a complete after-sale system.

Factory trainning support, Video technical support, online support, Engineers available to service machinery overseas.
